Want to add AI conversation features to your App?

Whether it's a customer service assistant, voice assistant, or interactive guide, Dialogflow can help you implement it. This article teaches you how to integrate Dialogflow into Android and Flutter to build mobile applications with natural language understanding capabilities.

If you're not yet familiar with Dialogflow, we recommend first reading the Dialogflow Complete Guide.

Mobile App Integration Method Comparison

💡 Key Takeaway: There are two main ways to integrate Dialogflow into an App, each with pros and cons.

Direct API Call

App directly calls Dialogflow API:

App → Dialogflow API → Response

Advantages:

• Simple architecture
• Lower latency
• No need to build backend

Disadvantages:

• API key exposed in App (security risk)
• Cannot add additional business logic
• Difficult to record conversation history

Backend Proxy

App calls Dialogflow through your backend:

App → Your Backend → Dialogflow API → Your Backend → App

Advantages:

• API key safely stored in backend
• Can add business logic (validation, logging, filtering)
• Easy to integrate with other systems

Disadvantages:

• Need to build and maintain backend
• Slightly higher latency
• More complex architecture

Analysis and Selection Recommendations

Recommendation: Production Apps should always use the backend proxy method.

Android Studio Integration

Project Setup

Step 1: Add Dependencies

In app/build.gradle add:

dependencies {
    implementation 'com.google.cloud:google-cloud-dialogflow:4.0.0'
    implementation 'io.grpc:grpc-okhttp:1.56.1'
    implementation 'com.google.auth:google-auth-library-oauth2-http:1.19.0'
}

Step 2: Configure Network Permissions

In AndroidManifest.xml add:

<uses-permission android:name="android.permission.INTERNET" />
<uses-permission android:name="android.permission.RECORD_AUDIO" />

Gradle Dependencies

Complete build.gradle configuration:

android {
    compileSdk 34

    defaultConfig {
        minSdk 24
        targetSdk 34
    }

    packagingOptions {
        exclude 'META-INF/INDEX.LIST'
        exclude 'META-INF/DEPENDENCIES'
    }
}

dependencies {
    implementation 'com.google.cloud:google-cloud-dialogflow:4.0.0'
    implementation 'io.grpc:grpc-okhttp:1.56.1'
    implementation 'io.grpc:grpc-stub:1.56.1'
}

Service Account Setup

Step 1: Get Key File

1. Go to Google Cloud Console > IAM > Service Accounts
2. Create or select service account
3. Download JSON key file

Step 2: Place Key (Development Use)

Place key file at app/src/main/res/raw/credentials.json

Note: This is only suitable for development testing. Use backend proxy for production.

DetectIntent API Call

Create Dialogflow client class:

class DialogflowClient(context: Context) {
    private val sessionsClient: SessionsClient
    private val session: SessionName
    private val projectId = "your-project-id"
    private val sessionId = UUID.randomUUID().toString()

    init {
        // Load credentials
        val stream = context.resources.openRawResource(R.raw.credentials)
        val credentials = GoogleCredentials.fromStream(stream)
            .createScoped(listOf("https://www.googleapis.com/auth/cloud-platform"))

        val settings = SessionsSettings.newBuilder()
            .setCredentialsProvider { credentials }
            .build()

        sessionsClient = SessionsClient.create(settings)
        session = SessionName.of(projectId, sessionId)
    }

    suspend fun detectIntent(text: String): String {
        return withContext(Dispatchers.IO) {
            val textInput = TextInput.newBuilder()
                .setText(text)
                .setLanguageCode("en-US")
                .build()

            val queryInput = QueryInput.newBuilder()
                .setText(textInput)
                .build()

            val request = DetectIntentRequest.newBuilder()
                .setSession(session.toString())
                .setQueryInput(queryInput)
                .build()

            val response = sessionsClient.detectIntent(request)
            response.queryResult.fulfillmentText
        }
    }

    fun close() {
        sessionsClient.close()
    }
}

Example Code

Complete Activity example:

class ChatActivity : AppCompatActivity() {
    private lateinit var dialogflowClient: DialogflowClient
    private lateinit var messageAdapter: MessageAdapter
    private val messages = mutableListOf<Message>()

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_chat)

        dialogflowClient = DialogflowClient(this)
        messageAdapter = MessageAdapter(messages)
        recyclerView.adapter = messageAdapter

        sendButton.setOnClickListener {
            val text = inputEditText.text.toString()
            if (text.isNotEmpty()) {
                sendMessage(text)
                inputEditText.text.clear()
            }
        }
    }

    private fun sendMessage(text: String) {
        // Display user message
        messages.add(Message(text, isUser = true))
        messageAdapter.notifyItemInserted(messages.size - 1)

        // Call Dialogflow
        lifecycleScope.launch {
            try {
                val response = dialogflowClient.detectIntent(text)
                messages.add(Message(response, isUser = false))
                messageAdapter.notifyItemInserted(messages.size - 1)
                recyclerView.scrollToPosition(messages.size - 1)
            } catch (e: Exception) {
                messages.add(Message("Sorry, an error occurred", isUser = false))
                messageAdapter.notifyItemInserted(messages.size - 1)
            }
        }
    }

    override fun onDestroy() {
        super.onDestroy()
        dialogflowClient.close()
    }
}

Flutter Integration

Package Selection

Flutter has several Dialogflow-related packages:

Recommendation: Use dialogflow_grpc or directly use HTTP API.

Cross-Platform Implementation

Step 1: Add Dependencies

In pubspec.yaml:

dependencies:
  flutter:
    sdk: flutter
  http: ^1.1.0
  uuid: ^4.0.0

Step 2: Create API Service

import 'dart:convert';
import 'package:http/http.dart' as http;
import 'package:uuid/uuid.dart';

class DialogflowService {
  final String projectId;
  final String accessToken; // Get from backend
  final String sessionId = Uuid().v4();

  DialogflowService({required this.projectId, required this.accessToken});

  Future<String> detectIntent(String text) async {
    final url = Uri.parse(
      'https://dialogflow.googleapis.com/v2/projects/$projectId/agent/sessions/$sessionId:detectIntent'
    );

    final response = await http.post(
      url,
      headers: {
        'Authorization': 'Bearer $accessToken',
        'Content-Type': 'application/json',
      },
      body: jsonEncode({
        'queryInput': {
          'text': {
            'text': text,
            'languageCode': 'en-US',
          },
        },
      }),
    );

    if (response.statusCode == 200) {
      final data = jsonDecode(response.body);
      return data['queryResult']['fulfillmentText'];
    } else {
      throw Exception('Dialogflow API error: ${response.statusCode}');
    }
  }
}

Example Widget

class ChatScreen extends StatefulWidget {
  @override
  _ChatScreenState createState() => _ChatScreenState();
}

class _ChatScreenState extends State<ChatScreen> {
  final TextEditingController _controller = TextEditingController();
  final List<ChatMessage> _messages = [];
  late DialogflowService _dialogflow;
  bool _isLoading = false;

  @override
  void initState() {
    super.initState();
    _dialogflow = DialogflowService(
      projectId: 'your-project-id',
      accessToken: 'your-access-token', // Should actually get from backend
    );
  }

  void _sendMessage() async {
    final text = _controller.text.trim();
    if (text.isEmpty) return;

    setState(() {
      _messages.add(ChatMessage(text: text, isUser: true));
      _isLoading = true;
    });
    _controller.clear();

    try {
      final response = await _dialogflow.detectIntent(text);
      setState(() {
        _messages.add(ChatMessage(text: response, isUser: false));
      });
    } catch (e) {
      setState(() {
        _messages.add(ChatMessage(text: 'Sorry, an error occurred', isUser: false));
      });
    } finally {
      setState(() => _isLoading = false);
    }
  }

  @override
  Widget build(BuildContext context) {
    return Scaffold(
      appBar: AppBar(title: Text('AI Assistant')),
      body: Column(
        children: [
          Expanded(
            child: ListView.builder(
              itemCount: _messages.length,
              itemBuilder: (context, index) {
                final message = _messages[index];
                return ChatBubble(
                  text: message.text,
                  isUser: message.isUser,
                );
              },
            ),
          ),
          if (_isLoading) LinearProgressIndicator(),
          _buildInputArea(),
        ],
      ),
    );
  }

  Widget _buildInputArea() {
    return Container(
      padding: EdgeInsets.all(8),
      child: Row(
        children: [
          Expanded(
            child: TextField(
              controller: _controller,
              decoration: InputDecoration(hintText: 'Enter message...'),
              onSubmitted: (_) => _sendMessage(),
            ),
          ),
          IconButton(
            icon: Icon(Icons.send),
            onPressed: _sendMessage,
          ),
        ],
      ),
    );
  }
}

State Management Integration

Use Provider to manage conversation state:

class ChatProvider extends ChangeNotifier {
  final List<ChatMessage> _messages = [];
  bool _isLoading = false;

  List<ChatMessage> get messages => _messages;
  bool get isLoading => _isLoading;

  Future<void> sendMessage(String text) async {
    _messages.add(ChatMessage(text: text, isUser: true));
    _isLoading = true;
    notifyListeners();

    try {
      final response = await _dialogflow.detectIntent(text);
      _messages.add(ChatMessage(text: response, isUser: false));
    } catch (e) {
      _messages.add(ChatMessage(text: 'An error occurred', isUser: false));
    } finally {
      _isLoading = false;
      notifyListeners();
    }
  }
}

Voice Assistant Features

Let App support voice input and output.

Speech-to-Text Integration

Android (using SpeechRecognizer):

class VoiceInputManager(private val context: Context) {
    private var speechRecognizer: SpeechRecognizer? = null
    private var onResult: ((String) -> Unit)? = null

    fun startListening(onResult: (String) -> Unit) {
        this.onResult = onResult

        speechRecognizer = SpeechRecognizer.createSpeechRecognizer(context)
        speechRecognizer?.setRecognitionListener(object : RecognitionListener {
            override fun onResults(results: Bundle?) {
                val matches = results?.getStringArrayList(SpeechRecognizer.RESULTS_RECOGNITION)
                matches?.firstOrNull()?.let { onResult(it) }
            }

            override fun onError(error: Int) {
                // Handle error
            }

            // Other required override methods...
        })

        val intent = Intent(RecognizerIntent.ACTION_RECOGNIZE_SPEECH).apply {
            putExtra(RecognizerIntent.EXTRA_LANGUAGE_MODEL, RecognizerIntent.LANGUAGE_MODEL_FREE_FORM)
            putExtra(RecognizerIntent.EXTRA_LANGUAGE, "en-US")
        }

        speechRecognizer?.startListening(intent)
    }

    fun stopListening() {
        speechRecognizer?.stopListening()
        speechRecognizer?.destroy()
    }
}

Flutter (using speech_to_text):

import 'package:speech_to_text/speech_to_text.dart' as stt;

class VoiceInput {
  final stt.SpeechToText _speech = stt.SpeechToText();
  bool _isListening = false;

  Future<void> initialize() async {
    await _speech.initialize();
  }

  void startListening(Function(String) onResult) {
    _speech.listen(
      onResult: (result) {
        if (result.finalResult) {
          onResult(result.recognizedWords);
        }
      },
      localeId: 'en_US',
    );
    _isListening = true;
  }

  void stopListening() {
    _speech.stop();
    _isListening = false;
  }
}

Text-to-Speech Playback

import 'package:flutter_tts/flutter_tts.dart';

class VoiceOutput {
  final FlutterTts _tts = FlutterTts();

  Future<void> initialize() async {
    await _tts.setLanguage('en-US');
    await _tts.setSpeechRate(0.5);
  }

  Future<void> speak(String text) async {
    await _tts.speak(text);
  }

  Future<void> stop() async {
    await _tts.stop();
  }
}

Continuous Dialogue Mode

Implement Siri-like continuous dialogue experience:

class ContinuousDialogue {
  final VoiceInput _voiceInput;
  final VoiceOutput _voiceOutput;
  final DialogflowService _dialogflow;

  bool _isActive = false;

  void startConversation() async {
    _isActive = true;

    while (_isActive) {
      // Voice input
      final userText = await _listenForInput();
      if (userText == 'end conversation') {
        _isActive = false;
        break;
      }

      // Call Dialogflow
      final response = await _dialogflow.detectIntent(userText);

      // Voice output
      await _voiceOutput.speak(response);

      // Brief wait before continuing to listen
      await Future.delayed(Duration(milliseconds: 500));
    }
  }
}

Security Considerations

Mobile App security is especially important—once API keys leak, they can't be retrieved.

API Key Protection Strategies

Never do this:

// ❌ Hard-coding key in code
val apiKey = "AIzaSyXXXXXXXXXXXXXXX"

Recommended approaches:

1. Use Backend Proxy (Recommended)

App → Your Backend (authentication + Dialogflow call) → App

Backend stores API key, App only communicates with backend.

2. Use Firebase Remote Config

val remoteConfig = Firebase.remoteConfig
remoteConfig.fetchAndActivate().addOnCompleteListener { task ->
    if (task.isSuccessful) {
        val apiKey = remoteConfig.getString("dialogflow_api_key")
    }
}

3. Use Android Keystore

val keyStore = KeyStore.getInstance("AndroidKeyStore")
keyStore.load(null)
// Securely store and retrieve keys

User Authentication Integration

Ensure only logged-in users can use AI features:

class SecureDialogflowClient(private val authService: AuthService) {

    suspend fun detectIntent(text: String): String {
        // Confirm user is logged in
        val user = authService.currentUser
            ?: throw UnauthorizedException("Please log in first")

        // Get access token
        val token = authService.getIdToken()

        // Call your backend (not directly calling Dialogflow)
        return apiService.chat(
            token = token,
            text = text
        )
    }
}

Sensitive Data Handling

Don't log sensitive conversations:

// ❌ Logging full conversation
Log.d("Chat", "User said: $userInput")

// ✓ Only log necessary information
Log.d("Chat", "User sent message, length: ${userInput.length}")

Clear local conversation history:

fun clearChatHistory() {
    // Clear memory
    messages.clear()

    // Clear local storage
    sharedPreferences.edit().remove("chat_history").apply()
}

Worried about API key security? Mobile App security issues are easily overlooked—once something happens, it's very troublesome. Book architecture consultation to have us help design secure integration architecture.

Release Considerations

App Store / Play Store Review

Privacy Policy Requirements:

If App collects conversation content, need to explain in privacy policy:

• What data is collected
• How data is used
• How long data is retained
• How users can delete data

Permission Explanations:

If using microphone permission, need to explain why:

• "Used for voice input, allowing you to speak with the AI assistant"

Performance Optimization

Reduce Startup Time:

// Lazy load Dialogflow client
private val dialogflowClient by lazy {
    DialogflowClient(applicationContext)
}

Background Processing:

// Process in background thread
viewModelScope.launch(Dispatchers.IO) {
    val response = dialogflowClient.detectIntent(text)
    withContext(Dispatchers.Main) {
        updateUI(response)
    }
}

Offline Handling

Handling when there's no network:

suspend fun detectIntent(text: String): String {
    if (!isNetworkAvailable()) {
        return "Currently no network connection, please try again later."
    }

    return try {
        dialogflowClient.detectIntent(text)
    } catch (e: IOException) {
        "Network connection unstable, please try again later."
    }
}

For more API integration details, refer to Dialogflow Fulfillment and API Integration Tutorial. For Intent design, refer to Dialogflow Intent and Context Tutorial. For cost estimation, refer to Dialogflow Pricing Complete Analysis.

Next Steps

After completing mobile integration, you can:

1. Optimize Conversation Design: Dialogflow Intent and Context Complete Tutorial
2. Develop Backend Integration: Dialogflow Fulfillment and API Integration Tutorial
3. Control Costs: Dialogflow Pricing Complete Analysis

Want to Add AI Conversation Features to Your App?

Integrating AI conversations in Apps involves many technical details: API integration, security, performance optimization, review compliance...

If you need:

• Add AI customer service features to existing App
• Develop new App with voice assistant
• Design secure and reliable integration architecture
• Cross-platform (iOS + Android) solution

Book AI implementation consultation to have an experienced team help you plan and implement.

We've helped multiple Apps successfully integrate AI conversation features, consultation is completely free.

Need Professional Cloud Advice?

Whether you're evaluating cloud platforms, optimizing existing architecture, or looking for cost-saving solutions, we can help

Book Free Consultation
